The V-VCPANEL-BK Volume Control Panel is a rack-mountable panel designed to house up to 6 Valcom volume controls or preamp volume controls. The V-VCPANEL-BK facilitates easy user access of multiple volume controls needing to be at one location. The V-VCPANEL-BK takes up 3 Rack Units in a standard 19.00-inch rack.
- Houses up to 6 volume controls 3U Rack mounting
- 18 gauge cold rolled steel construction
- 10-32 machine screws for mounting included
- Medium texture powder coat finish
Specifications
Dimensions & Weight
Cutout Dimensions:2.88in H x 2.0in W
(7.32cm x 5.08cm)
Panel Dimensions:
5.22in H x 19.00in W x 1.00inD
(13.26 cm x 48.26cm x 2.54cm)
Weight:
0.50lbs (0.23kg)
Shipping Weight:
3.40lbs (1.53kg)
